Wireless Triple Signal Detector

  • 90°@180° adjustable coverage
  • IP65 weather resistance for outdoor application
  • Active IR anti-masking
  • Multiple enrollment methods and easy installation
  • Frequency hopping against jamming for reliable transmission
View Less
View more
156
  • people viewed this product today!
  • 30-day money back guarantee

R2,605.00

Description

Specification

  • Detection Performance
  • Detection MethodPassive Infrared;Microwave
  • Detection Range15 m
  • Detection Angle90° @180° adjustable
  • Detection Zones92
  • Detectable Speed0.3～2m/s
  • SensitivityAuto;Low
  • White Light Filter10000lux
  • Microwave Frequency24GHz(24.15～24.25GHz)
  • Pet Immunity40 kg
  • Digital Temperature CompensationSupport
  • Anti-maskingSupport
  • Adaptable CoverageSupport, Pattern mask included
  • Feature
  • Digital ProcessingTri-Signal Logic
  • Sealed OpticsSupport
  • Tamper ProtectionFront;Rear
  • Environment Temperature IndicatorSupport
  • Signal Strength IndicatorSupport
  • Anti-Sway AnalyticsSupport
  • Interface
  • Power SwitchPower up enrolling
  • LED IndicatorGreen(Top PIR), Red(Microwave), Orange(Bottom PIR), Green+Orange(Mask), Blue(Alarm)
  • Transmission
  • Transmission TechnologyTri-X Wireless
  • Transmission MethodTwo-Way RF Wireless
  • Transmission Frequency868MHz
  • Transmission SecurityAES-128 Encryption
  • Transmission Range(Free Space)1.6Km
  • Frequency HoppingSupport
  • Enrolling MethodPower up;Remote ID;QR Code
  • Electrical Characteristics
  • Standard Battery LifeUp to 5 years (standby time)(The battery working time can be significantly reduced at low temperatures)
  • Power SupplyBattery powered
  • Battery TypeCR123A × 5
  • Typical Voltage3V
  • General
  • Operation Temperature-25°C to 60°C (-13°F to 140°F)
  • Storage Temperature-25°C to 60°C (-13°F to 140°F)
  • Operation Humidity10% to 90%
  • IP RateIP65
  • Dimension(WxHxD)75 mm × 202 mm × 73 mm
  • Weight600 g
  • Mounting Height0.8 m to 1.2 m
  • Mounting MethodWall
  • Application ScenarioOutdoor

*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Detection Performance
Detection Method
Passive Infrared;Microwave
Detection Range
15 m
Detection Angle
90° @180° adjustable
Detection Zones
92
Detectable Speed
0.3～2m/s
Sensitivity
Auto;Low
White Light Filter
10000lux
Microwave Frequency
24GHz(24.15～24.25GHz)
Pet Immunity
40 kg
Digital Temperature Compensation
Support
Anti-masking
Support
Adaptable Coverage
Support, Pattern mask included
Feature
Digital Processing
Tri-Signal Logic
Sealed Optics
Support
Tamper Protection
Front;Rear
Environment Temperature Indicator
Support
Signal Strength Indicator
Support
Anti-Sway Analytics
Support
Interface
Power Switch
Power up enrolling
LED Indicator
Green(Top PIR), Red(Microwave), Orange(Bottom PIR), Green+Orange(Mask), Blue(Alarm)
Transmission
Transmission Technology
Tri-X Wireless
Transmission Method
Two-Way RF Wireless
Transmission Frequency
868MHz
Transmission Security
AES-128 Encryption
Transmission Range(Free Space)
1.6Km
Frequency Hopping
Support
Enrolling Method
Power up;Remote ID;QR Code
Electrical Characteristics
Standard Battery Life
Up to 5 years (standby time)(The battery working time can be significantly reduced at low temperatures)
Power Supply
Battery powered
Battery Type
CR123A × 5
Typical Voltage
3V
General
Operation Temperature
-25°C to 60°C (-13°F to 140°F)
Storage Temperature
-25°C to 60°C (-13°F to 140°F)
Operation Humidity
10% to 90%
IP Rate
IP65
Dimension(WxHxD)
75 mm × 202 mm × 73 mm
Weight
600 g
Mounting Height
0.8 m to 1.2 m
Mounting Method
Wall
Application Scenario
Outdoor
For better user experience, we highly recommend you to update your device to the latest firmware asap.

Specification
Detection Performance
  • Detection MethodPassive Infrared;Microwave
  • Detection Range15 m
  • Detection Angle90° @180° adjustable
  • Detection Zones92
  • Detectable Speed0.3～2m/s
  • SensitivityAuto;Low
  • White Light Filter10000lux
  • Microwave Frequency24GHz(24.15～24.25GHz)
  • Pet Immunity40 kg
  • Digital Temperature CompensationSupport
  • Anti-maskingSupport
  • Adaptable CoverageSupport, Pattern mask included
Feature
  • Digital ProcessingTri-Signal Logic
  • Sealed OpticsSupport
  • Tamper ProtectionFront;Rear
  • Environment Temperature IndicatorSupport
  • Signal Strength IndicatorSupport
  • Anti-Sway AnalyticsSupport
Interface
  • Power SwitchPower up enrolling
  • LED IndicatorGreen(Top PIR), Red(Microwave), Orange(Bottom PIR), Green+Orange(Mask), Blue(Alarm)
Transmission
  • Transmission TechnologyTri-X Wireless
  • Transmission MethodTwo-Way RF Wireless
  • Transmission Frequency868MHz
  • Transmission SecurityAES-128 Encryption
  • Transmission Range(Free Space)1.6Km
  • Frequency HoppingSupport
  • Enrolling MethodPower up;Remote ID;QR Code
Electrical Characteristics
  • Standard Battery LifeUp to 5 years (standby time)(The battery working time can be significantly reduced at low temperatures)
  • Power SupplyBattery powered
  • Battery TypeCR123A × 5
  • Typical Voltage3V
General
  • Operation Temperature-25°C to 60°C (-13°F to 140°F)
  • Storage Temperature-25°C to 60°C (-13°F to 140°F)
  • Operation Humidity10% to 90%
  • IP RateIP65
  • Dimension(WxHxD)75 mm × 202 mm × 73 mm
  • Weight600 g
  • Mounting Height0.8 m to 1.2 m
  • Mounting MethodWall
  • Application ScenarioOutdoor

*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
