Description
Specification
- Interface
- USB Interface2 × USB 2.0
- Serial InterfaceNetwork, RS-232, RS-422, RS-485
- Network Interface10M/100M/1000M adaptive ethernet port; WiFi: Supported
- General
- Working Temperature-10 to +55° C (14 to 131° F)
- Working Humidity10% to 90%
- Net Weight1.7 kg (3.75 lb)
- Dimensions (W × H × D)404 mm × 163 mm × 180 mm (15.91″ × 6.42″ × 7.09″)
- Power Consumption≤15 W
- Power Supply12 VDC/PoE
- Display10.1″ TFT LCD touchscreen, Resolution: 1280 × 800
- Joystick4-axis joystick
- Video
- Video Output Interface Type1 ×HDMI, 1 ×DVI
- Audio
- Audio Input Interfaces1-ch, 3.5 mm connector (2.0 Vp-p, >1 KΩ)
- Audio Output Interfaces1-ch, 3.5 mm connector (2.0 Vp-p, 600 Ω)
- Video Decoding
- Video Decoding FormatH.264, H.264+, H.265, H.265+, MPEG4
- Video Decoding Capability1 channel of 4K@30fps, or 4 channels of 1,080P@30fps
- Certification
- Obtained CertificationCE-EMC/CE-LVD/ROHS/CB/UL/FCC-SDoC/RCM/BIS
