1/3″ Progressive Scan CMOS

2688 × 1520

Color: 0.001 Lux @ (F1.0, AGC ON),B/W: 0 Lux with IR

1/3 s to 1/100,000 s

IR cut filter

Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360°

Varifocal lens, motorized lens, 2.8 to 12 mm

2.8 to 12 mm, horizontal FOV 105.4° to 34.3°, vertical FOV 56.1° to 19.3°, diagonal FOV 125.8° to 39.4°

Ø14

Fixed

F1.0

1 m to ∞

Wide: D: 63.4m, O: 25.2 m, R: 12.7 m, I: 6.3 m Tele: D: 180.6 m, O: 71.7 m, R: 36.1 m, I: 18.1 m

IR

Up to 60 m

Yes

850 nm

50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.

Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.

32 Kbps to 8 Mbps

Baseline Profile,Main Profile,High Profile

Main Profile

CBR,VBR

H.264 and H.265 encoding

1 fixed region for main stream and sub-stream

G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)

8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Yes

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP

Up to 6 channels

Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP

Up to 32 users 3 user levels: administrator, operator, and user

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)

iVMS-4200,Hik-Connect,Hik-Central

Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Yes

Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

Day,Night,Auto,Schedule

BLC,HLC,3D DNR

≥ 52 dB

120 dB

4 programmable polygon privacy masks

1 RJ45 10 M/100 M self-adaptive Ethernet port

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

1 input, 1 output (max. 24 VDC/24 VAC, 1 A)

Yes

Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception

Scene change detection

Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning

Yes

Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)

12 VDC ± 25%, 1.08 A, max. 13 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3at, Class 4, max. 15 W

Front cover: Metal, body: Metal, bracket: Metal

298 mm × 97.9 mm × 95.7 mm (11.8″ × 3.9″ × 3.8″)

385 mm × 190 mm × 180 mm (15.2″ × 7.5″ × 7.1″)

Approx. 1490 g (3.3 lb.)

Approx. 2349 g (5.2 lb.)

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Heartbeat,mirror,password reset via email,pixel counter,anti-banding

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, IC: ICES-003: Issue 7, RCM: AS/NZS CISPR 32: 2015

CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017

CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

IP67: IEC 60529-2013,IK10: IEC 62262:2002
