1/1.8″ Progressive Scan CMOS

2688 × 1520

Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light

1/3 s to 1/100,000 s

IR cut filter

Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Fixed focal lens, 2.8 and 4 mm optional

2.8 mm, horizontal FOV 104.0°, vertical FOV 54.4°, diagonal FOV 126.7° 4 mm, horizontal FOV 89.2°, vertical FOV 45.5°, diagonal FOV 108.2°

M16

Fixed

F1.0

2.8 mm: 2.5 m to ∞ 4 mm: 3.1 m to ∞

2.8 mm: D: 61 m, O: 24 m, R: 12 m, I: 6 m 4 mm: D: 75 m, O: 30 m, R: 15 m, I: 7 m

IR,White Light

Up to 60 m

Yes

850 nm

50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *The third stream is supported under certain settings.

Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.

32 Kbps to 8 Mbps

Baseline Profile,Main Profile,High Profile

Main Profile

CBR,VBR

H.264 and H.265 encoding

1 fixed region for main stream and sub-stream

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP

Up to 6 channels

Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP

Up to 32 users 3 user levels: administrator, operator, and user

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)

NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)

iVMS-4200,Hik-Connect,Hik-Central

Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Yes

Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

Day,Night,Auto,Schedule

BLC,HLC,3D DNR

≥ 52 dB

130 dB

4 programmable polygon privacy masks

1 RJ45 10 M/100 M self-adaptive Ethernet port

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

Yes

Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception

Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email

Scene change detection

Yes

Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)

12 VDC ± 25%, 0.66 A, max. 8 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 9 W

Front cover: Metal, body: Metal, bracket: Metal

286.7 mm × 93.3 mm × 91.2 mm (11.3″ × 3.7″ × 3.6″)

386 mm × 156 mm × 155 mm (15.2″ × 6.1″ × 6.1″)

Approx. 1085 g (2.4 lb.)

Approx. 1639 g (3.6 lb.)

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Heartbeat,mirror,password reset via email,pixel counter,anti-banding

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
