1/3″ Progressive Scan CMOS

2688 × 1520

Color: 0.001 Lux @ (F1.0, AGC ON),B/W: 0 Lux with IR

1/3 s to 1/100,000 s

IR cut filter

Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°

Fixed focal lens, 2.8 and 4 mm optional

2.8 mm, horizontal FOV 100.2°, vertical FOV 54.7°, diagonal FOV 119.7° 4 mm, horizontal FOV 81.1°, vertical FOV 44.7°, diagonal FOV 94.6°

M12

Fixed

F1.0

2.8 mm: 1.9 m to ∞ 4 mm: 2.5 m to ∞

2.8mm: D: 63 m, O: 25 m, R: 12 m, I: 6 m 4mm: D: 78 m, O: 31 m, R: 15 m, I: 7 m

IR

Up to 30 m

Yes

850 nm

50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.

Main stream: H.265/H.264/H.265+/H.264+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings.

32 Kbps to 8 Mbps

Baseline Profile/Main Profile/High Profile

Main Profile

CBR/VBR

H.264 and H.265 encoding

1 fixed region for main stream and sub-stream

-U: mono sound

-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)

-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

-U: Yes

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets

Up to 6 channels

Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK

Up to 32 users. 3 user levels: administrator, operator and user

Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface

NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

iVMS-4200, Hik-Connect, Hik-Central

Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Yes

Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Day, Night, Auto, Schedule

120 dB

≥ 52 dB

BLC, HLC, 3D DNR

4 programmable polygon privacy masks

1 RJ45 10 M/100 M self-adaptive Ethernet port

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

-U: Yes

Yes

Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception

Scene change detection

Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email

Yes

Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle)
