Facial recognition, perimeter protection, motion detection 2.0

Facial recognition, perimeter protection, video structuralization, throwing objects from building, motion detection 2.0, ANPR, people counting, VCA

1, engine mode is adjustable

Face picture comparison, human face capture, face picture search

Wearing glasses, wearing a mask, facial expression, body temperature

Up to 16 face picture libraries, with up to 10,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 150 MB)

4-ch

1-ch human face capture (HD network camera, up to 4 MP, H.264/H.265)

32-ch

All channels

4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total

All channels

All channels

Plate number, license plate color, license plate type

Vehicle brand, vehicle color, vehicle type

32-ch Up to 12 MP resolution

256 Mbps

256 Mbps

4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output

1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI2/VGA independent output

1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI1/VGA simultaneous output

HDMI1/VGA simultaneous output, HDMI2/VGA independent output

1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480

1-ch, RCA (Linear, 1 KΩ)

1-ch, RCA (2.0 Vp-p, 1 KΩ)

H.265+/H.265/H.264+/H.264/MPEG4

12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF

16-ch

16-ch @ 1080p (30 fps)

Support

Video, Video & Audio

1/2/4/6/8/9/16/25/32/36

1/2/4/6/8/9/16/25/32/36

G.711ulaw/G.711alaw/G.722/G.726/MP2L2

1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

128

TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF(Version 2.2), OTAP

ONVIF (profile S/G); SDK; ISAPI

IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version

ONVIF(Version 2.5), RTSP

16, RJ-45 10/100 Mbps self-adaptive Ethernet interface

≤ 200 W

IEEE 802.3 af/at

RS-485 (half-duplex), RS-232, Keyboard

4 SATA interfaces supporting hot-plug

1 eSATA interface

Up to 16 TB capacity for each disk

16/4

Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0

Controllable 12 VDC, 0.5 A power output for external alarm device; The power will be turned on when the alarm output is triggered. *: The Ctrl 12V power is controlled by alarm output 9.

12 VDC, 1 A power output

English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian, Hebrew

100 to 240 VAC, 50 to 60 Hz Total power: ≤ 360 W

≤ 30 W (without HDD)

-10 ℃ to 55 ℃ (14 ℉ to 131 ℉)

10% to 90%

19-inch rack-mounted 1.5U chassis

445 × 400 ×75 mm ( 17.5″× 15.7″ × 3.0″)

≤ 7 kg (15.4 lb) (without HDD)

CE, CB, REACH, WEEE, UKCA, LOA

EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
