1/2.7″ Progressive Scan CMOS

1920 × 1080

Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR

1/3 s to 1/100,000 s

IR Cut Filter

Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Fixed

2.8 mm: horizontal FOV 111.6°, vertical FOV 59.1°, diagonal FOV 133.9° 4 mm: horizontal FOV 91.5°, vertical FOV 46.1°, diagonal FOV 109.8° 6 mm: horizontal FOV 56°, vertical FOV 29.8°, diagonal FOV 65.3°

M12

F1.6

IR

Up to 30 m

850 nm

50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)

50Hz: 25 fps (640 × 480, 640 × 360) 60Hz: 30 fps (640 × 480, 640 × 360)

Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG

32 Kbps to 8 Mbps

Baseline Profile/Main Profile/High Profile

Main Profile

Support 1 fixed region for main stream

Up to 6 channels

Open Network Video Interface, ISAPI

Up to 32 users. 3 levels: administrator, operator and user

Support Micro SD/SDHC/SDXC card (256 GB), local storage and NAS (NFS, SMB/CIFS), ANR

iVMS-4200, Hik-Connect, Hik-Central

Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+

Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser

Day, Night, Auto, Schedule

BLC, 3D DNR

120 dB

1 RJ45 10 M/100 M self-adaptive Ethernet port

Built-in Micro SD slot, up to 256 GB

Yes

Line crossing detection, intrusion detection

Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture

12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, Class 3, 36 to 57 V, 0.2 A to 0.15 A, max. 6.5 W

Metal, Plastic

69.7 mm × 67.9 mm × 171.4 mm (2.7″ × 2.7″ × 6.7″)

216 mm × 121 mm × 118 mm (8.5″ × 4.8″ × 4.7)

Approx. 350 g (0.8 lb.)

Approx. 450 g (1.0 lb.)

-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)

-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)

33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)

UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)

CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

IP67 (IEC 60529-2013)
