Name: 2 MP Fixed Outdoor IR WIFI Stand Alone PT Network Camera - My Kleine Winkel
SKU: DS-2DE2C200IWG/W(2.8MM)(W)(O-STD)/EU
Price: 1440.00 ZAR
Availability: InStock

Description

Camera
Image Sensor1/2.8″ Progressive Scan CMOS
Max. Resolution1920 × 1080
Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON),B/W: 0.005 Lux @ (F2.0, AGC ON),0 Lux with light

Lens
Focal Length2.8 mm, 4 mm
FOV2.8 mm, horizontal FOV 92°, vertical FOV 50°, diagonal FOV 110° 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 89°
ApertureF2.0

Illuminator
Supplement Light TypeIR
Supplement Light RangeIR distance: up to 30 m
IR Wavelength850 nm

PTZ
Movement Range (Pan)0° to 345°
Movement Range (Tilt)0° to 80°
Pan SpeedUp to 25°/s
Tilt SpeedUp to 20°/s

Video
Main Stream50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream50 Hz: 25 fps (768 × 432, 512 × 288) 60 Hz: 30 fps (768 × 432, 512 × 288)
Video CompressionMain stream: H.265/H.264, Sub-stream: H.265/H.264
Video Bit Rate256 Kbps to 1 Mbps
H.264 TypeBaseline profile,Main profile,High profile
H.265 TypeMain profile

Audio
Audio CompressionG.711,AAC-LC
Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw), 16 to 64 Kbps (AAC-LC)
Audio Sampling Rate8 kHz,16 kHz
Environment Noise FilteringYes

Network
ProtocolsTCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,UPnP,IGMP,QoS,IPv4,UDP,Bonjour,SSL/TLS
APIONVIF, SDK
SecurityPassword protection,HTTPS encryption,security audit log,basic and digest authentication for HTTP/HTTPS,TLS 1.1/1.2, WSSE for Open Network Video Interface

Wireless (Wi-Fi)
Encryption ModeWPA-PSK/WPA2-PSK
Wi-Fi ProtocolsIEEE802.11b,IEEE802.11g,IEEE802.11n
Frequency Range2.412 GHz to 2.472 GHz
Channel Bandwidth 20 MHz
Modulation802.11b: CCK,QPSK,BPSK, 802.11g: OFDM, 802.11n: OFDM
Transfer Rate11b: up to 54 Mbps,11g: up to 54 Mbps,11n: up to 150 Mbps
Wireless RangeUp to 50 m (The performance varies based on actual environment)

Image SettingsSaturation, brightness, contrast, and sharpness adjustable by client software
Wide Dynamic Range (WDR)Digital WDR

Interface
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Built-in Microphone1 built-in microphone
On-board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Speaker1 built-in speaker

Event
Basic EventMotion detection (support alarm triggering by specified target type (human and vehicle)), exception
LinkageUpload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite

Deep Learning Function
Perimeter ProtectionLine crossing, intrusion, region entrance, region exiting Support alarm triggered by specified target types (human and vehicle)

General
Power12 VDC ± 10%, 1 A, max. 10 W, Ø2 mm coaxial power plug, reverse polarity protection
Dimension163.9 mm × 185.8 mm × 131.9 mm (6.45″ × 7.31″ × 5.19″)
WeightCamera weight: 565 g (1.25 lb.) With package weight: 1020 g (2.25 lb.)
MaterialPlastic
Operating Condition-30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)
General Functionheartbeat,mirror

Approval
EMCCE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014)
SafetyCB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017)
EnvironmentCE-RoHS (2011/65/EU),WEEE (2012/19/EU)
ProtectionIP66 (IEC 60529-2013)

Camera

Image Sensor

1/2.8″ Progressive Scan CMOS

Max. Resolution

1920 × 1080

Min. Illumination

Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0.005 Lux @ (F2.0, AGC ON),0 Lux with light

Lens

Focal Length

2.8 mm, 4 mm

FOV

2.8 mm, horizontal FOV 92°, vertical FOV 50°, diagonal FOV 110° 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 89°

Aperture

F2.0

Illuminator

Supplement Light Type

Supplement Light Range

IR distance: up to 30 m

IR Wavelength

850 nm

PTZ

Movement Range (Pan)

0° to 345°

Movement Range (Tilt)

0° to 80°

Pan Speed

Up to 25°/s

Tilt Speed

Up to 20°/s

Video

Main Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (768 × 432, 512 × 288) 60 Hz: 30 fps (768 × 432, 512 × 288)

Video Compression

Main stream: H.265/H.264, Sub-stream: H.265/H.264

Video Bit Rate

256 Kbps to 1 Mbps

H.264 Type

Baseline profile,Main profile,High profile

H.265 Type

Main profile

Audio

Audio Compression

G.711,AAC-LC

Audio Bit Rate

64 Kbps (G.711ulaw/G.711alaw), 16 to 64 Kbps (AAC-LC)

Audio Sampling Rate

8 kHz,16 kHz

Environment Noise Filtering

Yes

Network

Protocols

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,UPnP,IGMP,QoS,IPv4,UDP,Bonjour,SSL/TLS

API

ONVIF, SDK

Security

Password protection,HTTPS encryption,security audit log,basic and digest authentication for HTTP/HTTPS,TLS 1.1/1.2, WSSE for Open Network Video Interface

Wireless (Wi-Fi)

Encryption Mode

WPA-PSK/WPA2-PSK

Wi-Fi Protocols

IEEE802.11b,IEEE802.11g,IEEE802.11n

Frequency Range

2.412 GHz to 2.472 GHz

Channel Bandwidth

20 MHz

Modulation

802.11b: CCK,QPSK,BPSK, 802.11g: OFDM, 802.11n: OFDM

Transfer Rate

11b: up to 54 Mbps,11g: up to 54 Mbps,11n: up to 150 Mbps

Wireless Range

Up to 50 m (The performance varies based on actual environment)


Image Settings

Saturation, brightness, contrast, and sharpness adjustable by client software

Wide Dynamic Range (WDR)

Digital WDR

Interface

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

Built-in Microphone

1 built-in microphone

On-board Storage

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

Built-in Speaker

1 built-in speaker

Event

Basic Event

Motion detection (support alarm triggering by specified target type (human and vehicle)), exception

Linkage

Upload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite

Deep Learning Function

Perimeter Protection

Line crossing, intrusion, region entrance, region exiting Support alarm triggered by specified target types (human and vehicle)

General

Power

12 VDC ± 10%, 1 A, max. 10 W, Ø2 mm coaxial power plug, reverse polarity protection

Dimension

163.9 mm × 185.8 mm × 131.9 mm (6.45″ × 7.31″ × 5.19″)

Weight

Camera weight: 565 g (1.25 lb.) With package weight: 1020 g (2.25 lb.)

Material

Plastic

Operating Condition

-30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)

General Function

heartbeat,mirror

Approval

EMC

CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014)

Safety

CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017)

Environment

CE-RoHS (2011/65/EU),WEEE (2012/19/EU)

Protection

IP66 (IEC 60529-2013)

Camera

Image Sensor1/2.8″ Progressive Scan CMOS
Max. Resolution1920 × 1080
Min. IlluminationColor: 0.01 Lux @ (F2.0, AGC ON),B/W: 0.005 Lux @ (F2.0, AGC ON),0 Lux with light

Lens

Focal Length2.8 mm, 4 mm
FOV2.8 mm, horizontal FOV 92°, vertical FOV 50°, diagonal FOV 110° 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 89°
ApertureF2.0

Illuminator

Supplement Light TypeIR
Supplement Light RangeIR distance: up to 30 m
IR Wavelength850 nm

PTZ

Movement Range (Pan)0° to 345°
Movement Range (Tilt)0° to 80°
Pan SpeedUp to 25°/s
Tilt SpeedUp to 20°/s

Video

Main Stream50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream50 Hz: 25 fps (768 × 432, 512 × 288) 60 Hz: 30 fps (768 × 432, 512 × 288)
Video CompressionMain stream: H.265/H.264, Sub-stream: H.265/H.264
Video Bit Rate256 Kbps to 1 Mbps
H.264 TypeBaseline profile,Main profile,High profile
H.265 TypeMain profile

Audio

Audio CompressionG.711,AAC-LC
Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw), 16 to 64 Kbps (AAC-LC)
Audio Sampling Rate8 kHz,16 kHz
Environment Noise FilteringYes

Network

ProtocolsTCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,UPnP,IGMP,QoS,IPv4,UDP,Bonjour,SSL/TLS
APIONVIF, SDK
SecurityPassword protection,HTTPS encryption,security audit log,basic and digest authentication for HTTP/HTTPS,TLS 1.1/1.2, WSSE for Open Network Video Interface

Wireless (Wi-Fi)

Encryption ModeWPA-PSK/WPA2-PSK
Wi-Fi ProtocolsIEEE802.11b,IEEE802.11g,IEEE802.11n
Frequency Range2.412 GHz to 2.472 GHz
Channel Bandwidth 20 MHz
Modulation802.11b: CCK,QPSK,BPSK, 802.11g: OFDM, 802.11n: OFDM
Transfer Rate11b: up to 54 Mbps,11g: up to 54 Mbps,11n: up to 150 Mbps
Wireless RangeUp to 50 m (The performance varies based on actual environment)


Image SettingsSaturation, brightness, contrast, and sharpness adjustable by client software
Wide Dynamic Range (WDR)Digital WDR

Interface

Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Built-in Microphone1 built-in microphone
On-board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Speaker1 built-in speaker

Event

Basic EventMotion detection (support alarm triggering by specified target type (human and vehicle)), exception
LinkageUpload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite

Deep Learning Function

Perimeter ProtectionLine crossing, intrusion, region entrance, region exiting Support alarm triggered by specified target types (human and vehicle)

General

Power12 VDC ± 10%, 1 A, max. 10 W, Ø2 mm coaxial power plug, reverse polarity protection
Dimension163.9 mm × 185.8 mm × 131.9 mm (6.45″ × 7.31″ × 5.19″)
WeightCamera weight: 565 g (1.25 lb.) With package weight: 1020 g (2.25 lb.)
MaterialPlastic
Operating Condition-30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)
General Functionheartbeat,mirror

Approval

EMCCE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014)
SafetyCB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017)
EnvironmentCE-RoHS (2011/65/EU),WEEE (2012/19/EU)
ProtectionIP66 (IEC 60529-2013)
